lng full containment storage tank
with the development of lng industry, lng storage is becoming more and more large and atmospheric, and the domestic design and manufacturing have reached 50000 m ³， in the coastal area, a single station with a capacity of 250000 m has been built ³、 160000 m ³ lng atmospheric storage tank is used to receive lng on board.
at present, the lng tanks designed, manufactured and installed in china are mainly 5000m long ³ and 10000m ³， it is widely used in lng liquefaction plants or lng peak shaving stations. the amount of lng produced by industrial tail gas is generally small, and 1000m is commonly used ³ lng storage tanks on the left and right.
introduce
main structure type
vertical, cylindrical, bimetal, inner ceiling, outer vault, high heat angle protection
the interlayer is protected by pearlescent sand, elastic felt and foam glass brick.
process system
01. purge system
02. inlet system
03. discharge system (external and submerged)
04. pump backflow system
05. interlayer nitrogen supply system
06. liquid level and pressure measurement system
07. temperature measurement system
08. gas discharge system
09. bog pipeline system
10. analytical sampling system
11. safety system
12. pressure stabilizing system
13. fire alarming system
configuration parameter
design, manufacture and acceptance standard of lng storage tank
european standard bsen14620 "design and field manufacture of vertical, cylindrical, flat bottomed, cooled liquefied storage tanks with operating temperatures between 0 ℃ and - 165 ℃"
● jb / t9077-1999 general insulated powder tank
● jb / t4735-1997 steel welded atmospheric pressure vessels
american standard api620 design and construction of large welded low pressure storage tank
● jb / t4730-2005 nondestructive testing of pump equipment
code for construction and acceptance of vertical cylindrical steel welded storage tank (gb 50128-2005)
● gb / t20368-2006 liquefied natural gas (lng) production, storage, transportation and loading
